Hatz 2G40 User Manual

Technical data 2G40, 2G40 H
20
HATZ
Operator’s Manual
4 Technical data
4.1 Engine information and filling quantities
Type 2G40, 2G40 H
Type Air cooled, four stroke diesel engine
Combustion system Direct injection
Number of cylinders 2
Bore/stroke mm 92 / 75
Displacement cm
3
997
Engine oil capacity
without oil sump
With oil sump
Approx.
L.
2.5
1)
3.0
1)
Difference between the
"max." and "min."
marks
Approx.
L.
0.8
1)
Engine oil consumption
(after running-in period)
Approx. 1% of fuel consumption, pertaining to full load
Engine oil pressure Min. 1.0bar at 900rpm
Sense of rotation on
power take-off side Left
Tappet clearance
at 10 - 30°C
inlet/outlet mm 0.10
Max. perm. continuous
sloping position in the di-
rection:
without
oil sump
with
oil sump
Exhaust low
Exhaust high
Flywheel low
Flywheel high
30
2)
17
2)
25
2)
25
2)
30
2)
17
2)
30
2)
25
2)
Weight Approx.
kg
106
Battery capacity Min/max 12V – 45 / 88Ah
24V – 36 / 55Ah
Version H: with power take-off for the operation of hydraulic pumps
1)
These values are approximations only. The max. mark on the dipstick is
decisive in any case (see section 7.6 Check the oil level, page 43).
2)
Exceeding these limit values causes engine damage!

Hatz 2G40 Specifications

General

Displacement	462 cm³
Cooling System	Air-cooled
Compression Ratio	20.5:1
Fuel Type	Diesel
Fuel System	Direct injection
Starting System	Electric starter
Engine Type	1-cylinder 4-stroke diesel engine
Lubrication System	Forced lubrication
