DS-7108HI-S series Net DVR User Manual
7
2.3 Rear Panel Description
2 1 7 8 3 12 6 4 5
1310911
Fig 2-1 DS-7108HI-S Rear panel
Notice: Please refer to real product for different models.
DS-7108HI-S
① Video in ② Video out ③VGA interface
④ Alarm in ⑤Alarm out ⑥ Power switch
⑦Audio in ⑧Audio out ⑨UTP interface
⑩RS485 T+ T- R+ R- ⑪RS232 interface ⑫Video loop output
⑬+12V DC power supply
