User Manual of Digital Video Recorder
103
8.1 Setting Motion Detection
Steps:
1. Enter Motion Detection interface and choose a camera you want to set motion detection.
Menu> Camera> Motion
Figure 8. 1 Motion Detection Settings Interface
2. Set detection area and sensitivity.
Check checkbox to enable motion detection, use the mouse to draw detection area(s) and drag the
sensitivity bar to set sensitivity.
Figure 8. 2 Set Detection Area and Sensitivity
3. Click to configure the motion detection settings. Click Trigger Channel tab and select one or more
channels which will start to record or become full-screen monitoring when motion alarm is triggered.
Click to save the settings.
Figure 8. 3 Set Trigger Camera of Motion Detection
