User Manual of Digital Video Recorder
58
5.3 Configuring Motion Detection Recording
Purpose:
Follow the steps to set the motion detection parameters. In the live view mode, once a motion detection event
takes place, the device can analyze it and perform some response actions to handle it. Enabling motion detection
function can trigger certain channels to start recording, or trigger full screen monitoring, audible warning, notify
the surveillance center and so on. In this chapter, you can follow the steps to schedule a record which triggered
by the detected motion.
Steps:
1. Enter the Motion Detection interface.
Menu>Camera>Motion
Figure 5. 15 Motion Detection
2. Configure Motion Detection:
1) Choose camera you want to configure.
2) Check checkbox to enable motion detection.
3) Drag and draw the area for motion detection by mouse. If you want to set the motion detection
for all the area shot by the camera, click . To clear the motion detection area,
click .
4) Click to configure the motion detection settings in the pop-up message box.
Figure 5. 16 Motion Detection Settings
5) Select the channels which you want the motion detection event to trigger recording.
6) Click to save the settings.
7) Click to back to the upper level menu.
8) Click in the Motion Detection interface to save the settings. Exit the Motion
Detection interface.
