User Manual of Digital Video Recorder
144
10.3 Managing HDD Group
10.3.1 Setting HDD Groups
Purpose:
Multiple HDDs can be managed in groups. Video from specified channels can be recorded onto a particular HDD
group through HDD settings.
Steps:
1. Enter the Storage Mode interface.
Menu > HDD > Advanced
2. Set the Mode to Group, as shown below.
Note: The device must be rebooted to activate the changes.
Figure 10. 11 Storage Mode Interface
3. Click and the following Attention box will pop up.
Figure 10. 12 Attention for Reboot
4. Click to reboot the device to activate the changes.
5. After reboot of device, enter the HDD Information interface.
Menu > HDD > General
6. Select a HDD from the list and click to enter the Local HDD Settings interface.
