User Manual of Digital Video Recorder
60
5.4 Configuring Alarm Triggered Recording
Purpose:
Follow the procedure to configure alarm triggered recording.
Steps:
1. Enter the Alarm setting interface.
Menu> Configuration> Alarm
Figure 5. 18 Alarm Settings
2. Click Alarm Input tab.
Figure 5. 19 Alarm Settings- Alarm Input
1) Select Alarm Input No. and configure alarm parameters.
2) Edit the alarm name as desired and choose N.O (normally open) or N.C (normally closed) for
alarm type.
3) Check checkbox to enable the alarm input.
4) Click to configure the alarm settings.
