User Manual of Digital Video Recorder
48
4.2.6 Calling Patterns
Purpose:
Follow the procedure to move the PTZ camera according to the predefined patterns.
Calling pattern in the PTZ setting interface
Steps:
1. Enter the PTZ Control interface.
Menu> Camera> PTZ> More Settings
2. Select the pattern number.
3. Click , then the PTZ moves according to the pattern. Click to stop it.
Figure 4. 12 PTZ- Calling Pattern
Call pattern in live view mode.
Steps:
1. In the live view mode, press PTZ control on the front panel or on the remote control, or click PTZ Control
icon on the quick setting toolbar.
2. Choose Camera in the list on the menu.
3. And then choose Pattern on the control bar.
4. Double-click the pattern number you want to call, or you can select the pattern number and click to
call the pattern.
Figure 4. 13 PTZ Panel- Pattern
To Next Page
