Network Video Recorder User Manual
64
The movement of the PTZ is recorded as the pattern.
5.2.6 Calling Patterns
Purpose:
Follow the procedure to move the PTZ camera according to the predefined patterns.
Step 1 Click the button PTZ in the lower-right corner of the PTZ setting interface;
Or press the PTZ button on the front panel or click the PTZ Control icon in the quick
setting bar, or select the PTZ option in the right-click menu to show the PTZ control panel.
Step 2 Click the button to show the general settings of the PTZ control.
Figure 5-9 PTZ Panel - General
Step 3 Click the Call Pattern button to call it.
Step 4 Click the Stop Pattern button to stop calling it.
5.2.7 Customizing Linear Scan Limit
Purpose:
The Linear Scan can be enabled to trigger the scan in the horizantal direction in the predefined
range.
This function is supported by some certain models.
Step 1 Go to Menu > Camera >PTZ.
