Deskstar T7K500 Hard Disk Drive Specification
148
12.10 Identify Device (ECh)
Table 81: Identify Device command (ECh)
The Identify Device command requests the device to transfer configuration information to the host. The device will
transfer a sector to the host containing the information in Table 82 beginning on page 149.
An asterisk (*) in next to the Content field indicates the use of those parameters that are vendor specific.
Command Block Output Registers Command Block Input Registers
Register 7 6 5 4 3 2 1 0 Register 7 6 5 4 3 2 1 0
Data - - - - - - - - Data - - - - - - - -
Feature - - - - - - - - Error see below
Sector Count - - - - - - - - Sector Count - - - - - - - -
Sector Number - - - - - - - - Sector Number - - - - - - - -
Cylinder Low - - - - - - - - Cylinder Low - - - - - - - -
Cylinder High - - - - - - - - Cylinder High - - - - - - - -
Device/Head 1 - 1 D - - - - Device/Head - - - - - - - -
Command 1 1 1 0 1 1 0 0 Status see below
Error Register Status Register
7654321 0 76543 21 0
CRC UNC 0 IDN 0 ABT T0N AMN BSY RDY DF DSC DRQ COR IDX ERR
00000V0 0 0V0-- 0- V
