Deskstar T7K500 Hard Disk Drive Specification
165
12.16 Read DMA Ext (25h)
Table 93: Read DMA Ext Command (25h)
The Read DMA command reads one or more sectors of data from disk media, then transfers the data from the
device to the host.
The sectors are transferred through the Data Register 16 bits at a time.
The host initializes a slave-DMA channel prior to issuing the command. The data transfers are qualified by
DMARQ and are performed by the slave-DMA channel. The device issues only one interrupt per command to indi-
cate that data transfer has terminated and status is available.
If an uncorrectable error occurs, the read will be terminated at the failing sector.
Output parameters to the device
Sector Count Current The number of sectors to be transferred low order, bits (7:0).
Sector Count Previous The number of sectors to be transferred high order, bits (15:8). If 0000h in the
Sector Count register is specified, then 65,536 sectors will be transferred.
Sector Number Current LBA (7:0)
Sector Number Previous LBA (31:24)
Cylinder Low Current LBA (15:8)
Cylinder Low Previous LBA (39:32)
Command Block Output Registers Command Block Input Registers
Register 7 6 5 4 3 2 1 0 Register 7 6 5 4 3 2 1 0
Data Low - - - - - - - - Data Low - - - - - - - -
Data High - - - - - - - - Data High - - - - - - - -
Feature
Current - - - - - - - -
Error see below
Previous - - - - - - - -
Sector
Count
Current V V V V V V V V
Sector
Count
HOB=0 - - - - - - - -
Previous V V V V V V V V HOB=1 - - - - - - - -
Sector
Number
Current V V V V V V V V
Sector
Number
HOB=0 V V V V V V V V
Previous V V V V V V V V HOB=1 V V V V V V V V
Cylinder
Low
Current V V V V V V V V
Cylinder
Low
HOB=0 V V V V V V V V
Previous V V V V V V V V HOB=1 V V V V V V V V
Cylinder
High
Current V V V V V V V V Cylinder
High
HOB=0 V V V V V V V V
Previous V V V V V V V V HOB=1 V V V V V V V V
Device/Head 1 1 1 0 - - - - Device/Head - - - - - - - -
Command 0 0 1 0 0 1 0 1 Status See below ...
Error Register Status Register
7654321 0 76543 21 0
CRC UNC 0 IDN 0 ABT T0N AMN BSY RDY DF DSC DRQ COR IDX ERR
VVs0V0V0 0 0V0V- 0- V
