Deskstar T7K500 Hard Disk Drive Specification
266
12.57 Write Stream PIO (3Bh)
Table 164: Write Stream PIO Command (3Bh)
This command writes from 1 to 65536 sectors as specified in the Sector Count register. A sector count of 0
requests 65536 sectors.
If the Write Continuous bit is set to one, the device shall not stop execution of the command due to errors. If the
WC bit is set to one and errors occur in the transfer or writing of the data, the device shall continue to transfer the
amount of data requested and then provide ending status with the BSY bit cleared to zero, the SE bit set to one, the
ERR bit cleared to zero, and the type of error, IDNF, or ABRT, reported in the error log. If the WC bit is set to one
and the Command Completion Time Limit expires, the device shall stop execution of the command and provide
ending status with BSY bit cleared to zero, the SE bit set to one, the ERR bit cleared to zero, and report the fact that
the Command Completion Time Limit expired by setting the CCTO bit in the error log to one, In all cases, the
device shall attempt to transfer the amount of data requested within the Command Completion Time Limit event if
some data transferred is in error.
Command Block Output Registers Command Block Input Registers
Register 7 6 5 4 3 2 1 0 Register 7 6 5 4 3 2 1 0
Data Low - - - - - - - - Data Low - - - - - - - -
Data High - - - - - - - - Data High - - - - - - - -
Feature
Current V V V V - V V V
Error See below
Previous V V V V V V V V
Sector
Count
Current V V V V V V V V
Sector
Count
HOB=0 - - - - - - - -
Previous V V V V V V V V HOB=1 - - - - - - - -
Sector
Number
Current V V V V V V V V
Sector
Number
HOB=0 V V V V V V V V
Previous V V V V V V V V HOB=1 V V V V V V V V
Cylinder
Low
Current V V V V V V V V
Cylinder
Low
HOB=0 V V V V V V V V
Previous V V V V V V V V HOB=1 V V V V V V V V
Cylinder
High
Current V V V V V V V V Cylinder
High
HOB=0 V V V V V V V V
Previous V V V V V V V V HOB=1 V V V V V V V V
Device/Head 1 1 1 D - - - - Device/Head - - - - - - - -
Command 0 0 1 1 1 0 1 0 Status See below ...
Error Register Status Register
7654321 0 76543 21 0
CRC UNC 0 IDN 0 ABT T0N AMN BSY RDY DF DSC DRQ COR IDX ERR
VV0V0V0 V 0VVV- 0- V
