Deskstar T7K500 Hard Disk Drive Specification
241
12.43 Standby (E2h/96h)
Table 152: Standby (E2h/96h)
The Standby command causes the device to enter the Standby Mode immediately and to set the auto power down
time-out parameter (standby timer).
When the Standby mode is entered, the drive is spun down but the interface remains active. If the drive is already
spun down, the spin down sequence is not executed.
During the Standby mode the drive will respond to commands but there is a delay while waiting for the spindle to
reach operating speed.
The automatic power down sequence is enabled and the timer starts counting down when the drive returns to Idle
mode
Output parameters to the device
Sector Count Time-out Parameter. If it is 0, the time-out interval (Standby Timer) is NOT disabled. If it is non-
zero, the automatic power down sequence is enabled. The time-out interval is shown below.
Command Block Output Registers Command Block Input Registers
Register 7 6 5 4 3 2 1 0 Register 7 6 5 4 3 2 1 0
Data - - - - - - - - Data - - - - - - - -
Feature - - - - - - - - Error see below
Sector Count V V V V V V V V Sector Count - - - - - - - -
Sector Number - - - - - - - - Sector Number - - - - - - - -
Cylinder Low - - - - - - - - Cylinder Low - - - - - - - -
Cylinder High - - - - - - - - Cylinder High - - - - - - - -
Device/Head 1 - 1 D - - - - Device/Head - - - - - - - -
Command 1 1 1 0 0 0 1 0 Status see below
Error Register Status Register
7654321 0 76543 21 0
CRC UNC 0 IDN 0 ABT T0N AMN BSY RDY DF DSC DRQ COR IDX ERR
00000V0 0 0V0V- 0- V
Value Time-out
0 Timer disabled
1-240 Value x 5 seconds
241-251 (Value-240) x 30 minutes
252 21 minutes
253 8 hours
254 21 minutes 10 seconds
255 21 minutes 15 seconds
