Deskstar T7K500 Hard Disk Drive Specification
47
7.1.4.3 Capacity clip to 32GB
The figure below shows the jumper positions used to select Device 0, Device 1, Cable Selection, or Device1
(Slave) Present while setting the drive capacity down to 32 GB for the purpose of compatibility.
Table 35: Jumper positions for capacity clip to 32GB
Note: The jumper setting acts as a 32GB clip which clips the LBA to 66055248. The CHS is unchanged from the
factory default of 16383/16/63.
7.1.4.4 Power up in Standby
The figure below shows the jumper positions used to select Device 0, Device 1, Cable Selection, or Device1
(Slave) Present to enable Power Up In Standby.
Table 36: Jumper settings for Disabling Auto Spin
G
I
ECA
HFDB
DEVICE 0 (Master)
G
I
ECA
HFDB
DEVICE 1 (Slave)
G
I
ECA
HFDB
CABLE SEL
G
I
ECA
HFDB
DEVICE 1 (Slave) Present
G
I
ECA
HFDB
DEVICE 0 (Master)
G
I
ECA
HFDB
DEVICE 1 (Slave)
G
I
ECA
HFDB
CABLE SEL
G
I
ECA
HFDB
DEVICE 1 (Slave) Present
