Deskstar T7K500 Hard Disk Drive Specification
203
12.32 Security Erase Unit (F4h)
Table 122: Security Erase Unit (F4h)
The Security Erase Unit command initializes all user data sectors and then disables the device lock function.
Note that the Security Erase Unit command initializes from LBA 0 to Native MAX LBA. The Host MAX LBA is
set by the Initialize Drive Parameter, Device Configuration Overlay or the Set MAX ADDRESS command is
ignored. The protected area by the Set MAX ADDRESS command is also initialized.
This command requests the transfer of a single sector of data from the host including information specified in the
table below.
If the password does not match, the device rejects the command with an Aborted error.
Table 123: Erase Unit information
Identifier Zero indicates that the device should check the supplied password against the user pass-
word stored internally. One indicates that the device should check the given password
against the master password stored internally.
The Security Erase Unit command erases all user data and disables the security mode feature (device lock func-
tion). After the completion of this command, all the user data will be initialized to zero with a write operation. At
this time, the data write is not verified with a read operation to determine if the data sector is initialized correctly.
Command Block Output Registers Command Block Input Registers
Register 7 6 5 4 3 2 1 0 Register 7 6 5 4 3 2 1 0
Data - - - - - - - - Data - - - - - - - -
Feature - - - - - - - - Error see below
Sector Count - - - - - - - - Sector Count - - - - - - - -
Sector Number - - - - - - - - Sector Number - - - - - - - -
Cylinder Low - - - - - - - - Cylinder Low - - - - - - - -
Cylinder High - - - - - - - - Cylinder High - - - - - - - -
Device/Head 1 - 1 D - - - - Device/Head - - - - - - - -
Command 1 1 1 1 0 1 0 0 Status see below
Error Register Status Register
7654321 0 76543 21 0
CRC UNC 0 IDN 0 ABT T0N AMN BSY RDY DF DSC DRQ COR IDX ERR
000V0V0 0 0V0V- 0- V
Word Description
00 Control Word
bit 0 : Identifier (1- Master, 0- User)
bit 1 : Erase mode (1- Enhanced, 0 - Normal)
[Enhanced mode is not supported]
bit 2-15 : Reserved
01-16 Password (32 bytes)
17-255 Reserved
