Deskstar T7K500 Hard Disk Drive Specification
208
12.35 Security Unlock (F2h)
Table 127: Security Unlock command (F2h)
This command unlocks the password and causes the device to enter device unlock mode. If a power on reset or
hard reset is done without executing the Security Disable Password command after this command is completed, the
device will be in device lock mode. The password has not been changed yet.
The Security Unlock command requests the transfer of a single sector of data from the host including information
specified in the table below.
If the Identifier bit is set to master and the drive is in high security mode, the password supplied will be compared
with the stored master password. If the drive is in maximum security mode, the security unlock will be rejected.
If the Identifier bit is set to user, the drive compares the supplied password with the stored user password.
If the password compare fails, the device returns an abort error to the host and decrements the unlock attempt
counter. This counter is initially set to five and is decremented for each password mismatch. When this counter
reaches zero, all password protected commands are rejected until there is a hard reset or a power off.
Identifier
A zero indicates that the device regards Password as the User Password. A one indicates that the device regards
Password as the Master Password.
Command Block Output Registers Command Block Input Registers
Register 7 6 5 4 3 2 1 0 Register 7 6 5 4 3 2 1 0
Data - - - - - - - - Data - - - - - - - -
Feature - - - - - - - - Error see below
Sector Count - - - - - - - - Sector Count - - - - - - - -
Sector Number - - - - - - - - Sector Number - - - - - - - -
Cylinder Low - - - - - - - - Cylinder Low - - - - - - - -
Cylinder High - - - - - - - - Cylinder High - - - - - - - -
Device/Head 1 - 1 D - - - - Device/Head - - - - - - - -
Command 1 1 1 1 0 0 1 1 Status see below
Error Register Status Register
7654321 0 76543 21 0
CRC UNC 0 IDN 0 ABT T0N AMN BSY RDY DF DSC DRQ COR IDX ERR
00000V0 0 0V0V- 0- V
Word Description
00 Control Word
bit 0 : Identifier (1- Master, 0- User)
bit 1-15 : Reserved
01-16 Password (32 bytes)
17-255 Reserved
