Deskstar T7K500 Hard Disk Drive Specification
244
12.45 Write Buffer (E8h)
Table 154: Write Buffer (E8h)
The Write Buffer command transfers a sector of data from the host to the sector buffer of the device. The sectors of
data are transferred through the Data Register 16 bits at a time.
The Read Buffer and Write Buffer commands are synchronized such that sequential Write Buffer and Read Buffer
commands access the same 512 byte within the buffer.
Command Block Output Registers Command Block Input Registers
Register 7 6 5 4 3 2 1 0 Register 7 6 5 4 3 2 1 0
Data - - - - - - - - Data - - - - - - - -
Feature - - - - - - - - Error see below
Sector Count - - - - - - - - Sector Count - - - - - - - -
Sector Number - - - - - - - - Sector Number - - - - - - - -
Cylinder Low - - - - - - - - Cylinder Low - - - - - - - -
Cylinder High - - - - - - - - Cylinder High - - - - - - - -
Device/Head 1 - 1 D - - - - Device/Head - - - - - - - -
Command 1 1 1 0 1 0 0 0 Status see below
Error Register Status Register
7654321 0 76543 21 0
CRC UNC 0 IDN 0 ABT T0N AMN BSY RDY DF DSC DRQ COR IDX ERR
00000V0 0 0V0-- 0- V
