Hitachi PB Series User Manual

Section 3 3.4 Setting Repeat Print z 3–21
3.4 Setting Repeat Print
3.4.1 Overview
This function is used to print the same print description continuously.
Configure the "Repeat intervals" and "Repeat count" settings for repeat print.
1 Repeat print intervals:
z The size of the print target can be specified.
z This setting is performed when print targets are transported in close contact to
each other (i.e. without gaps between them).
Single-character
width = (horizontal
character size + inter-
character space) x
character increased
width setting
Trailing character
correction value =
inter-character space
x character increased
width setting + 1
z Perform the following calculations to obtain the printing intervals for repeat
print:
(i) On an individual scan basis:
(single-character width x number of characters – trailing character
correction value) x (print target size/print width of all characters)
(ii) On an individual character basis: Number of characters x (print target size/
print width of all characters)
(Example) Print target size: 64 mm; print width of all characters: 25 mm;
number of characters: 6; character size: 5 x 7 dots; inter-character
space: 2 dots
• On an individual scan basis:
((5 + 2) x 1 x 6 – (2 x 1 + 1)) x (64 / 25) = 99.84  100
• On an individual character basis:
6 x (64 / 25) = 15.36  15
z Round the calculation result to the nearest integer number.
2 Repeat print count
z You can preset the number of repeat print sequences to be performed while the
sensor light is blocked.
z If repeat print is not needed, set the value to "0".
z The repeat print mode will be "Fixed during Signal ON".
z The relationship between repeat print mode and the count is as shown below.
Mode
Setting
2~9998 9999
Signal ON
period
Printing is repeated a
preselected number of times at
predefined intervals while the
print target detection signal is
ON.
Repeat print is performed while
the print target detection signal
is ON.
Signal trigger Not supported.
Print target Print target
Repeat print intervals
