Honda BF250D User Manual

100
OPERATION
If the engine oil pressure drops and/
or the engine overheats, either or both
warning systems could be activated.
When activated the engine speed will
decrease gradually and the green oil
pressure indicator will turn OFF and
the red overheat indicator will turn
ON. A continuous buzzer will sound
on all type.
The engine speed can not be
increased with a larger throttle
opening until the malfunction is
corrected.
When the malfunction is corrected
the engine speed will increase
gradually.
If the engine overheats, the engine
will stop in 20 seconds after the
engine protection system will limit
engine speed.
Each warning system of PGM-FI,
ACG, oil pressure, overheat, and
water separator is activated as
described in the following table.
OIL PRESSURE
INDICATOR
(GREEN)
ACG
INDICATOR
(RED)
OVERHEAT
INDICATOR
(RED)
BUZZER
(R1 type)
PGM-FI
INDICATOR
(RED)
BUZZER
OVERHEAT
INDICATOR
(RED)
OIL PRESSURE
INDICATOR
(GREEN)
(R2, R3 type)
PGM-FI
INDICATOR
(RED)
ACG
INDICATOR
(RED)
PGM-FI
INDICATOR
(RED)
OIL PRESSURE
INDICATOR
(RED)
ACG
INDICATOR
(RED)
(Display Assy type)
OVERHEAT
INDICATOR
(RED)
Engine Protection System
<Engine Oil Pressure, Overheat,
Water Separator, PGM-FI and
ACG Warning Systems>
42ZVL600.book 100 ページ ２０１８年７月１９日 木曜日 午前９時６分

Honda BF250D Specifications

General

Brand	Honda
Model	BF250D
Category	Outboard Motor
Language	English
