CONTROLS AND FEATURES
For multiple outboard motors, the
trim/tilt angle of all outboard motors
is adjusted at the same time by using
the power trim/tilt switch on the
remote control lever and the trim/tilt
angle of each outboard motor is
adjusted by using each power trim/tilt
switch on the panel.
(D1 type)
REMOTE CONTROL
LEVER
POWER
TRIM/TILT
SWITCH
(D2 type)
SINGLE TYPE
REMOTE
CONTROL
LEVER
POWER
TRIM/TILT
SWITCH
DUAL TYPE
POWER
TRIM/TILT
SWITCH
REMOTE CONTROL
LEVERS
DUAL TYPE
TRIPLE TYPE
POWER TRIM/TILT SWITCH
PTT SWITCH PANEL
㻰㻺
㼁㻼
㻰㻺
㼁㻼
3257 67%'
㻰㻺
㼁㻼
㻰㻺
㼁㻼
㻰㻺
㼁㻼
3257 67%'&(17(5
