83
OPERATION
While pulling the neutral release
lever, move the control lever
approximately 32° toward the
FORWARD or REVERSE position to
engage the desired gear.
Moving the control lever further from
approximately 32° will increase
throttle opening and boat speed.
The control lever will not move
unless the neutral release lever is
pulled up.
Avoid sharp and abrupt operation
of the control lever. Operate it
moderately. Operate the control
lever and raise the engine speed
after making sure that the gear
was shifted securely.
Gear Shifting
(R1 type)
NEUTRAL RELEASE LEVER
REMOTE CONTROL
LEVER
Pull up
MAXIMUM
OPENING
FORWARD
NEUTRAL
32°
FORWARD
REVERSE
NEUTRAL
REVERSE
MAXIMUM
OPENING
32°
NEUTRAL
42ZVL600.book 83 ページ ２０１８年７月１９日 木曜日 午前９時６分
