105
OPERATION
<Over-rev Limiter>
This outboard motor is equipped with
an engine over-rev limiter which
activates when the engine speed
increases excessively. The over-rev
limiter can be activated while
cruising, tilting up the outboard
motor, or when ventilation occurs
during a sharp turn.
When the over-rev limiter is
activated:
1. Reduce the throttle opening
immediately and check the trim
angle.
2. If the trim angle is correct but the
over-rev limiter stays activated,
stop the engine, check the
condition of the outboard motor,
check to see if the correct propeller
is installed and check it for
damage.
Correct or service as necessary, by
contacting your authorized Honda
outboard motor dealer.
<Anode>
The anode is a sacrificial material
which helps to protect the outboard
motor from corrosion.
Painting or coating the anode will
lead to rust and corrosion damage
to the outboard motor.
There are also 4 small sacrificial
anodes in the water passages of the
engine block.
<Power Reduction>
This outboard motor is equipped with
the power reduction system which
activates when the outboard motor
has a serious problem.
The power reduction system
decreases the engine speed to protect
engine until the malfunction is
corrected.
When one of the two systems of the
remote control sensor is faulty, the
power reduction system does not
decrease the engine speed.
ANODE
(stern bracket)
ANODE
(each side)
Power reduction
