145
16. SPECIFICATIONS
MODEL BF200D
Description
Code
BBRJ
Type XRV XCRV
Overall length 948 mm (37.3 in)
Overall width 660 mm (26.0 in)
Overall height 1,916 mm (75.4 in)
Transom height
(when Transom
angle at 12°)
635 mm (25.0 in)
Dry mass
[weight]*
284 kg (626 lbs) 285 kg (628 lbs)
Rated power 147.1 kW (200 PS)
Full throttle
range
5,000 – 6,000 min
-1
(rpm)
Engine type 4 stroke OHC 6-cylinder (V6)
Displacement
3,583 cm
3
(218.6 cu-in)
Spark plug gap 1.0 – 1.1 mm (0.039 – 0.043 in)
Remote control
steering system
Motor-mounted
Starter system Electric starter
Ignition system Full transistor battery
Lubrication
system
Trochoid pump pressure lubrication
Specified oil Engine: API standard SG, SH, SJ, SL SAE 10W-30
Gear case: API standard (GL-4) SAE 90 Hypoid gear oil
Oil capacity Engine: Without oil filter replacement:
7.6 L (8.0 US qt, 6.7 Imp qt)
With oil filter replacement:
7.8 L (8.2 US qt, 6.9 Imp qt)
Gear case: 1.47 L (1.55 US qt, 1.29 Imp qt)
D.C. output 12 V – 60 A
Cooling system Water cooling with thermostat
Exhaust system Underwater exhaust
Spark plugs ZFR6K-11E (NGK)
Fuel pump Electromagnetic type
Fuel Unleaded gasoline
(91 research octane, 86 pump octane, or higher)
Gear change Forward – Neutral – Reverse (Dog clutch)
Steering angle 30° right and left
Tilt up angle 68° (when Transom angle is 12°)
Trim angle – 4° to 16°
(when Transom angle is 12°)
* Without battery cable, with propeller
Honda outboards are power rated in accordance with ISO8665 (propeller shaft output).
