42
CONTROLS AND FEATURES
Cooling Water Check Hole
The cooling water is checked here to
see whether it is circulating inside the
engine properly.
After starting the engine, check at the
cooling water check hole whether the
cooling water is circulating through
the engine.
Cooling Water Intake Port
The engine cooling water is drawn
into the engine through this port.
Engine Cover Latches
Pull the engine cover latches to
remove the engine cover.
COOLING WATER INTAKE PORT
(each side)
Side
ENGINE COVER LATCH (each side)
