8
Conguring the settings
When you press the [MENU BACK] button on the engine information screen, the MENU screen appears.
* In the Multi-Function Display set on an inactive station, which has no operation authority, Not Available is shown instead of BOAT SET in the
MENU screen, preventing BOAT SET from being selected.
Be sure to congure the settings in the Multi-Function Display set on an active station. (P.39)
<MENU screen>
Active station Inactive station
List of setting methods
The following titles allow you to check the setting method according to your target setting.
Multiple settings are required for the following functions, which are available on some models. Check the following and congure
the settings appropriately.
• Setting the trim support function : (9) > (1) > (4) > (3)
• Setting the automatic tilt function : ( (5) + (7) ) > (2)
* The following setting items are explained in the order laid out in the Multi-Function Display.
* Be sure to congure "(9) Trim Zero Set" regardless of whether the trim support is used or not because it corrects the trim sensor.
* Click/tap any of the following titles to display the page for that title.
BOAT SET
(1) Speed Source
(2) Automatic Tilt
(3) Trim Support
(4) Trim Support Setting
(5) Tilt Limit Set
(6) Tilt Limit Reset
(7) Trim Limit Set
(8) Trim Limit Reset
(9) Trim Zero Set
(10) Fuel Tank Preset
SCREEN EDIT
(14) Layout
(15) Boost press
(16) Engine Temp
(17) Battery Voltage
(18) Fuel Flow
INFORMATION
(11) Engine Warnings
(12) Maintenance Reminder
(13) NMEA2000 Device List
SYSTEM
(19) Brightness
(20) Background
(21) Units
(22) Speed Display
(23) Station
(24) Language
(25) Alarms Pop-up
(26) Demo Mode
(27) Reset Fuel Used
(28) Reset Engine Number
(29) Reset Factory
To Next Page
