IO
Remove the wire harness.
11.
Remove the ba\lcry box.
IV.
FRAME
12 Remo
ve
the brake pedal, stop switch and main stand.
13.
Remove the side
stand
14.
Using
·'Ball Race Remover" (Tool
No.
07946- 3290200)
and ;,Driver Handle" (Tool No.
07949-6110000), re•
move the upper and bottom ball races.
Inspection
I.
Check the entire frame for distortion, damage, crack
or
any other defect
2 Check the steel'ing head pipe for misalignment
or
deformation
3.
Check the
wire
harness, connectors for breakage. proper
connection, damage
or
any other defect
4. Check the fuel hose for deterioration; also for cracks
or
any other imperfections
5.
Check the
fue
l filler cap for cloggin~
6.
Check the fuel tank for deformation. cracks
or
other•
wise
signs
of
leaks. Also check the interior and,
if
necessary.
clean
Assembly
I.
Drive
fiL
the
baU
race using "Ball Race Driver Attach•
ment" (Tool No.
07946 3290100) and "Driver Handle"
(Tool No.
07949-61
I 0000).
Evenly drive
in
the ball race.
59
Fig.
4-80
(I)
Ball
race remover (2)
Ual
l race
Fig
.
4-81
(1)
Fuel filler cap
(2)
Fuel filler cap hole
,--..
(
···---
--'
Fig.
4-82
(I)
Uall
race driver attaclunent
(2)
Driver handle
(3)
Ball
race
