Honda CRF450L 2019 User Manual

128 Servicing Your Honda
Tires & Tubes
The tires that came on your motorcycle were
designed to match the performance capabilities of
your motorcycle and provide the best combination
of handling, braking, durability, and comfort.
When replacing, use the original equipment tires or
equivalent tires of the same size, construction,
speed rating, and load range as the originals.
The recommended tires for your motorcycle are:
Whenever you replace a tire, remember:
• Have the wheel balanced after the tire is
installed.
• Have the tire replaced by your dealer if
possible.
• Have a new tube installed whenever a tire is
replaced. The old tube will probably be
stretched. If installed in a new tire, it could fail.
If you have a tire professionally replaced at a non-
Honda facility, we recommend that you have the
work checked by your Honda dealer.
Tire Replacement
WARNING
Installing improper tires on your
motorcycle can affect handling and
stability. This can cause a crash in which
you can be seriously hurt or killed.
Always use the size and type of tires
recommended in this owner’s manual.
Front
80/100-21 M/C 51P
IRC GP-21F
Rear
120/80-18 M/C 62P
IRC GP-22R
Type bias-ply, tube

Honda CRF450L 2019 Specifications

General

Engine Type	449cc liquid-cooled single-cylinder four-stroke
Bore x Stroke	96.0mm x 62.1mm
Compression Ratio	12.0:1
Fuel System	Programmed Fuel Injection (PGM-FI), 46mm throttle body
Transmission	6-speed
Rear Brake	Single 240mm disc
Front Tire	80/100-21
Rear Tire	120/80-18
Rake (Caster Angle)	28.5°
Wheelbase	58.9 inches
Seat Height	37.1 inches
Fuel Capacity	2.0 gallons
Ignition	Full transistorized ignition
Ground Clearance	12.4 inches
Front Suspension	49mm inverted fork; 12.0 inches of travel
Rear Suspension	Pro-Link Showa single shock, adjustable spring preload, compression and rebound damping
Front Brake	Single 260mm disc
Curb Weight	289 pounds
Valve Train	Unicam four-valve
Final Drive	Chain
Trail	4.6 inches (118mm)
