12 Instruments & Controls
Indicators & Displays
The speedometer shows riding speed in miles or
kilometers per hour.
The odometer shows the total miles or kilometers
ridden.
The odometer can be displayed from 0 to 999,999
miles (kilometers).
The tripmeter A and tripmeter B show number of
miles or kilometers ridden since you last reset the
tripmeter.
To select the odometer, tripmeter A or tripmeter B,
push the SEL button (1).
The tripmeter return to 0 when the read-out
exceeds 9,999.9 miles (kilometers).
To Reset
the Tripmeter, Average Fuel Mileage and
Fuel Consumption
Press the SEL button (1) to select the TRIP A (2),
average fuel mileage A (3), fuel consumption A
(4), TRIP B, average fuel mileage B or fuel
consumption B.
To reset tripmeter, average fuel mileage, and fuel
consumption, press and hold SEL button with
tripmeter, average fuel mileage, or fuel
consumption displayed.
When they are reset, reset display appears at each
indication. Then, the display returns to the last
selected indication.
The fuel mileage meter includes the following
functions:
current fuel mileage
average fuel mileage
fuel consumption
The unit of the indication depends on the unit
which you select (page 14).
If the speed and mileage unit is set to ‘‘km/h’’/‘‘km,’’
the indication mode of the current and average fuel
mileage can be selected km/L or L/100 km (page 14).
If the speed and mileage unit is set to ‘‘mph’’/
‘‘mile’’, the fuel mileage unit shows “mile/gal”.
Press the SEL button to change the indication to
the current fuel mileage, average fuel mileage A,
average fuel mileage B, fuel consumption A or fuel
consumption B.
Current Fuel Mileage
Current fuel mileage shows the current, or instant
fuel mileage you are getting. When your
motorcycle speed is 4 mph (6 km/h) or below,
“---.- (--.-)” is displayed. When “---.- (--.-)” is
displayed except for the above mentioned cases, go
to your dealer for service.
Average Fuel Mileage
The average fuel mileage is based on the each
tripmeter A and tripmeter B. The average fuel
mileage since tripmeter was reset. When
“---.- (--.-) ” is displayed, see your dealer for
service. Average fuel mileage is also reset when
the tripmeter is reset (see previous step).
Fuel Consumption
The fuel consumption is based on the each
tripmeter A and tripmeter B. The fuel consumption
since tripmeter was reset. When “---.-” is
displayed, see your dealer for service.
Speedometer
Odometer/Tripmeter A & B
(1) SEL button
(1)
(1) SEL button (3) fuel mileage A
(2) TRIP A (4) fuel consumption A
(2)
For example TRIP A, Average Fuel Mileage A and
Fuel Consumption A:
(3)
(4)
(2)
(3)
(4)
(1)
Fuel Mileage Meter
