Honda CRF450L 2019 User Manual

Side Cover
Servicing Your Honda 47
Refer to Important Safety Precautions on page 33.
Rem
oval
1. Remove the seat (page 46).
2. Remove the side cover (1) by removing the
bolts (2).
The right and left side covers can be removed in
the same manner.
Installation
1. Install the side cover (1), and then tighten the
bolts (2) to the specified torque:
7 lbf·ft (10 N·m, 1.0 kgf·m)
The right and left side covers can be installed in the
same manner.
2. Install the seat (page 46).
(1) side cover
(2) bolts
(1)
(2)
(1) side cover
(2) bolts
(1)
(2)

Honda CRF450L 2019 Specifications

General

Engine Type	449cc liquid-cooled single-cylinder four-stroke
Bore x Stroke	96.0mm x 62.1mm
Compression Ratio	12.0:1
Fuel System	Programmed Fuel Injection (PGM-FI), 46mm throttle body
Transmission	6-speed
Rear Brake	Single 240mm disc
Front Tire	80/100-21
Rear Tire	120/80-18
Rake (Caster Angle)	28.5°
Wheelbase	58.9 inches
Seat Height	37.1 inches
Fuel Capacity	2.0 gallons
Ignition	Full transistorized ignition
Ground Clearance	12.4 inches
Front Suspension	49mm inverted fork; 12.0 inches of travel
Rear Suspension	Pro-Link Showa single shock, adjustable spring preload, compression and rebound damping
Front Brake	Single 260mm disc
Curb Weight	289 pounds
Valve Train	Unicam four-valve
Final Drive	Chain
Trail	4.6 inches (118mm)
