The ignition switch (1) is used for starting and
stopping the engine (page 26) and to lock the
steering for theft prevention (page 29). Insert the
key and turn it to the right for the ON position.
Push down on the key and turn it to the left to the
LOCK (steering lock) position.
Leaving the ignition switch in the ON position
with the engine stopped will drain the battery.
Do not turn the key while riding.
The start button (1) is used for starting the engine.
Pushing the button in starts the engine. See
Starting Procedure, page 25.
The starter motor will not operate if the engine stop
switch is in the (Stop) position when the start
button is pushed.
The engine stop switch (2) is used to stop the
engine in an emergency. To operate, push the
switch to the (Stop) position.
The switch must be in the (Run) position to
start the engine, and it should normally remain in
the (Run) position even when the engine is
OFF.
If your motorcycle is stopped with the ignition
switch ON and the engine stop switch (Stop)
position, the headlight, position light, taillight and
license light will remain on, resulting in battery
discharge.
The headlight dimmer switch (1) is used to change
between the high and low beams of the headlight.
To operate, press the switch to (HI) for high
beam, (Lo) for low beam.
When this switch (2) is pressed, the headlight
flashes on to signal approaching cars or when
passing.
The turn signal switch (3) is used to signal a turn or
a lane change. To operate, move the switch all the
way in the proper direction and release it. The
appropriate turn signal lights will start blinking. To
cancel the light, push the switch in.
The horn is used to alert other motorists.
To operate, push the horn button (4).
Ignition Switch
Key Position Function
ON Electrical circuits on.
OFF No electrical circuits function.
LOCK
(steering lock)
No electrical circuits function.
Locks the steering head.
(1) ignition switch
Start Button
(1) start button (2) engine stop switch
Engine Stop Switch
(1)
(2)
Headlight Dimmer Switch
(1) headlight dimmer switch
(2) passing light control switch
(3) turn signal switch
(4) horn button
Passing Light Control Switch
Turn Signal Switch
Horn Button
