Honda HRN216VKA User Manual

11-3
HRN216 HANDLEBAR/ CABLES/CONTROLS
5. Unlock both handle locking knobs and fold the
handlebar over the mower into the storage position.
6. Remove both handle locking knobs (P. 11 -1 0
).
7. Have an assistant hold and support the handlebar and
then remove the two special bolts and the handlebar
from the handle stays.
8. Install the handlebar in the reverse order of its removal.
• Install new cable ties and position them properly (P. 2-21
).
HANDLE
LOCKING
KNOBS
SPECIAL
BOLTS

Honda HRN216VKA Specifications

General

Engine	Honda GCV170
Cutting Width	21 inches
Starter	Recoil
Deck Material	Steel
Mulching Capability	Yes
Bag Capacity	2.5 bushels
Bagging Capability	Yes
Cutting Height Range	1.0 - 4.0 inches
Discharge	Side
Drive Type	Self-Propelled, Variable Speed
