8-6
FUEL SYSTEM HRN216
4. Remove the 5 x 6 mm screw covering the pilot jet.
5. Clean the float valve seat using carburetor cleaner and
compressed air.
6. Clean the main nozzle thoroughly using carburetor cleaner,
appropriate size jet cleaning tool, and compressed air. Do not
use a welding tip cleaning needle.
N OTICE
Using a welding tip cleaning needle or a jet needle that is too
large may damage the carburetor. Never force a needle, and
never use a needle with a bent or damaged tip.
Inspect the center and side holes for damage or contamination
by holding the main nozzle up to a light to verify they are clean.
TOOL: Jet cleaner 07JPZ-001010B
7. Clean the main jet by spraying carburetor cleaner through the
jet and using the appropriate size jet cleaning tool and
compressed air. Do not use a welding tip cleaning needle.
Carefully inspect the main jet for damage or contamination.
FLOAT
VALVE
SEAT

Honda HRN216VKA Specifications

General

Engine	Honda GCV170
Cutting Width	21 inches
Starter	Recoil
Deck Material	Steel
Mulching Capability	Yes
Bag Capacity	2.5 bushels
Bagging Capability	Yes
Cutting Height Range	1.0 - 4.0 inches
Discharge	Side
Drive Type	Self-Propelled, Variable Speed
