Honda VFR 800 User Manual

111
Specifications
Specifications
*1 Including rider, passenger, all luggage, and accessories
*2 Includes the weight of the luggage and added accessories.
■ Main Components
Type RC60
Overall length 2,130 mm (83.9 in)
Overall width 800 mm (31.5 in)
Overall height 1,240 mm (48.8 in)
Wheelbase 1,465 mm (57.7 in)
Minimum ground
clearance
140 mm (5.5 in)
Caster angle 25° 45’
Trail 96 mm (3.8 in)
Curb weight 238 kg (525 lb)
Maximum weight
capacity
*1
195 kg (430 lb)
Maximum luggage
weight
*2
33 kg (73 lb)
Passenger capacity Rider and 1 passenger
Minimum turning
radius
2.80 m (9.19 ft)
Displacement 782 cm
3
(47.70 cu-in)
Bore x stroke 72 x 48 mm (2.83 x 1.89 in)
Compression ratio 11.6 : 1
Fuel
Unleaded petrol
Recommended: 91 RON or higher
Tank capacity 21 litres (5.55 US gal, 4.62 Imp gal)
Battery
12V-10Ah (10 HR) or
12V-11Ah (10 HR) / 11.6Ah (20 HR)
Gear ratios
1st 2.846
2nd 2.062
3rd 1.578
4th 1.291
5th 1.111
6th 0.965
Reduction ratios
(primary / final)
1.939 / 2.687
32MGY600.indb 111 2011/01/11 16:28:38

Honda VFR 800 Specifications

General

Displacement	782cc
Compression Ratio	11.6:1
Transmission	6-speed
Bore x Stroke	72mm x 48mm
Final Drive	Chain
Front Suspension	43 mm telescopic fork, adjustable preload, compression and rebound damping
Front Brakes	Dual 296mm discs with CBS three-piston calipers
Rear Brakes	Single 256 mm disc with 2-piston caliper
Front Tire	120/70ZR-17
Rear Tire	180/55ZR-17
