Honda VFR 800 User Manual

56
Maintenance
Removing & Installing Body Components
a
Clip C
❙
Installation
1. Slightly open the retaining pawls and
then push them out.
2. Insert the clip into the hole.
3. Lightly press down on the centre pin to
lock the clip.
1
2 3
Clip C
The clip C must be removed to remove the
left rear cowl.
❙
Removal
1. Remove the pin by a Phillips screwdriver.
2. Pull the clip out of the hole.
1
2
❙
Installation
1. Insert the clip into the hole.
2. Push the pin in.
1
2
32MGY600.indb 56 2011/01/11 16:28:01

Honda VFR 800 Specifications

General

Displacement	782cc
Compression Ratio	11.6:1
Transmission	6-speed
Bore x Stroke	72mm x 48mm
Final Drive	Chain
Front Suspension	43 mm telescopic fork, adjustable preload, compression and rebound damping
Front Brakes	Dual 296mm discs with CBS three-piston calipers
Rear Brakes	Single 256 mm disc with 2-piston caliper
Front Tire	120/70ZR-17
Rear Tire	180/55ZR-17
