Maintenance
Removing & Installing Body Components
a
Left Rear Cowl
Left Rear Cowl
Hook
Left rear cowl
Clip C
Tabs
Bolt
Slot
The left rear cowl must be removed to
remove the battery.
❙
Removal
1. Remove the seat.
P.54
2. Remove the clip C and bolt.
3. Release the rear cowl tabs from the rear
fender slots.
a
Carefully release the tabs.
4. Release the hook from the slot by pulling
the left rear cowl back, then remove the
left rear cowl.
a
Be careful not to apply weight to the
rear cowl.
❙
Installation
Install the parts in the reverse order of
removal.
32MGY600.indb 59 2011/01/11 16:28:05

Honda VFR 800 Specifications

General

Displacement	782cc
Compression Ratio	11.6:1
Transmission	6-speed
Bore x Stroke	72mm x 48mm
Final Drive	Chain
Front Suspension	43 mm telescopic fork, adjustable preload, compression and rebound damping
Front Brakes	Dual 296mm discs with CBS three-piston calipers
Rear Brakes	Single 256 mm disc with 2-piston caliper
Front Tire	120/70ZR-17
Rear Tire	180/55ZR-17
