Honda VFR 800 User Manual

93
Troubleshooting
Electrical Trouble
a
Burned-out Light Bulb
❙
Headlight Bulb
Bulb retainers
Dust cover
Tabs
Bulb
High beam
socket
Low beam
socket
Grooves
The high and low beam headlight bulbs
replacement can be done in the same way.
1. Remove the dust cover.
2. Pull the socket off the bulb without
turning it.
3. Unhook the bulb retainers and pull out
the bulb without turning it.
4. Install a new bulb and parts in the reverse
order of removal.
a
Make sure the dust cover tabs and
headlight housing grooves are aligned.
a
Be careful not to confuse the high
beam and low beam headlight sockets.
Do not touch the glass surface with your
fingers. If you touch the bulb with your bare
hands, clean it with a cloth moistened with
alcohol.
32MGY600.indb 93 2011/01/11 16:28:31

Honda VFR 800 Specifications

General

Displacement	782cc
Compression Ratio	11.6:1
Transmission	6-speed
Bore x Stroke	72mm x 48mm
Final Drive	Chain
Front Suspension	43 mm telescopic fork, adjustable preload, compression and rebound damping
Front Brakes	Dual 296mm discs with CBS three-piston calipers
Rear Brakes	Single 256 mm disc with 2-piston caliper
Front Tire	120/70ZR-17
Rear Tire	180/55ZR-17
