Honda VFR 800 User Manual

67
Maintenance
Brakes/Clutch
Checking Brake Fluid
1. Place your motorcycle in an upright
position on a firm, level surface.
2.
Front
Check that the brake fluid reservoir
cap is horizontal and that the fluid level is
above the lower level mark.
3.
Rear
Remove the seat.
P.54
4.
Rear
Check that the brake fluid reservoir
is horizontal and that the level is between
the lower level and upper level marks.
If the brake fluid level in either reservoir is
below the lower level mark or the brake
lever and pedal freeplay becomes excessive,
inspect the brake pads for wear. If the brake
pads are not worn, you most likely have a
leak. Have your motorcycle inspected by
your dealer.
Rear brake fluid reservoir
Upper level
mark
Lower level
mark
Rear
Front brake fluid reservoir
Lower level
mark
Front
32MGY600.indb 67 2011/01/11 16:28:11

Honda VFR 800 Specifications

General

Displacement	782cc
Compression Ratio	11.6:1
Transmission	6-speed
Bore x Stroke	72mm x 48mm
Final Drive	Chain
Front Suspension	43 mm telescopic fork, adjustable preload, compression and rebound damping
Front Brakes	Dual 296mm discs with CBS three-piston calipers
Rear Brakes	Single 256 mm disc with 2-piston caliper
Front Tire	120/70ZR-17
Rear Tire	180/55ZR-17
