Honda VFR 800 User Manual

55
Maintenance
Removing & Installing Body Components
a
Clip A
Clip A
The clip A must be removed to remove the
spoiler and the right front side cowl.
❙
Removal
1. Press down on the centre pin to release
the lock.
2. Pull the clip out of the hole.
Centre
pin
❙
Installation
1. Push the bottom of the centre pin.
2. Insert the clip into the hole.
3. Press down on the centre pin to lock the
clip.
Clip B
The clip B must be removed to remove the
right front side cowl.
❙
Removal
1. Press down on the centre pin to release
the lock.
2. Pull the clip out of the hole.
1
2
continued
32MGY600.indb 55 2011/01/11 16:28:00

Honda VFR 800 Specifications

General

Displacement	782cc
Compression Ratio	11.6:1
Transmission	6-speed
Bore x Stroke	72mm x 48mm
Final Drive	Chain
Front Suspension	43 mm telescopic fork, adjustable preload, compression and rebound damping
Front Brakes	Dual 296mm discs with CBS three-piston calipers
Rear Brakes	Single 256 mm disc with 2-piston caliper
Front Tire	120/70ZR-17
Rear Tire	180/55ZR-17
