Troubleshooting
Electrical Trouble
a
Blown Fuse
Blown Fuse
Before handling fuses, see “Inspecting and
Replacing Fuses”.
P.4 6
❙
Fuse Box Fuses
Fuse box cover
Spare fuses
1. Remove the seat.
P.54
2. Remove the fuse box cover.
3. Pull the fuses out with the fuse puller in
the tool kit and check for a blown fuse.
Always replace a blown fuse with a spare
of the same rating.
4. Reinstall the fuse box cover.
5. Reinstall the seat.
32MGY600.indb 96 2011/01/11 16:28:35

Honda VFR 800 Specifications

General

Displacement	782cc
Compression Ratio	11.6:1
Transmission	6-speed
Bore x Stroke	72mm x 48mm
Final Drive	Chain
Front Suspension	43 mm telescopic fork, adjustable preload, compression and rebound damping
Front Brakes	Dual 296mm discs with CBS three-piston calipers
Rear Brakes	Single 256 mm disc with 2-piston caliper
Front Tire	120/70ZR-17
Rear Tire	180/55ZR-17
