Honda VFR 800 User Manual

113
Specifications
Specifications
Recommended drive
chain lubricant
Drive chain lubricant designed
specifically for O-ring chains
Drive chain slack 30 to 40 mm (1.2 to 1.6 in)
Standard drive chain
DID 50VA8 or RK 50HFOZ5
No. of links 110
Standard sprocket sizes
Engine sprocket 16T
Rear wheel sprocket 43T
■ B u l b s
Headlight 12V-55W x 2
Brakelight LED
Tail light LED
Front turn signal lights 12V-21W x 2
Rear turn signal lights 12V-21W x 2
Position light 12V-5W x 2
License plate light 12V-5W
■ F u s e s
Main fuse 30A
Other fuses 30A, 20A, 10A
■ Torque Specifications
Engine oil drain bolt 30 N·m (3.1 kgf·m, 22 lbf·ft)
Oil filter 26 N·m (2.7 kgf·m, 19 lbf·ft)
Bearing holder pinch bolt 74 N·m (7.5 kgf·m, 55 lbf·ft)
Front wheel axle bolt 59 N·m (6.0 kgf·m, 44 lbf·ft)
Front wheel brake caliper
mounting bolts
31 N·m (3.2 kgf·m, 23 lbf·ft)
Front wheel axle pinch bolts 22 N·m (2.2 kgf·m, 16 lbf·ft)
Rear wheel nuts 108 N·m (11.0 kgf·m, 80 lbf·ft)
Muffler band bolts 21 N·m (2.1 kgf·m, 15 lbf·ft)
32MGY600.indb 113 2011/01/11 16:28:39

Honda VFR 800 Specifications

General

Displacement	782cc
Compression Ratio	11.6:1
Transmission	6-speed
Bore x Stroke	72mm x 48mm
Final Drive	Chain
Front Suspension	43 mm telescopic fork, adjustable preload, compression and rebound damping
Front Brakes	Dual 296mm discs with CBS three-piston calipers
Rear Brakes	Single 256 mm disc with 2-piston caliper
Front Tire	120/70ZR-17
Rear Tire	180/55ZR-17
