Honda VFR 800 User Manual

61
Maintenance
Engine Oil
Checking the Engine Oil
1. If the engine is cold, idle the engine for 3
to 5 minutes.
2. Turn the ignition switch OFF, stop the
engine and wait 2 to 3 minutes.
3. Place your motorcycle in an upright
position on a firm, level surface.
4. Check that the oil level is between the
upper and lower level marks in the oil
inspection window.
Oil inspection
window
Upper level
Lower level
Oil fill cap
32MGY600.indb 61 2011/01/11 16:28:06

Honda VFR 800 Specifications

General

Displacement	782cc
Compression Ratio	11.6:1
Transmission	6-speed
Bore x Stroke	72mm x 48mm
Final Drive	Chain
Front Suspension	43 mm telescopic fork, adjustable preload, compression and rebound damping
Front Brakes	Dual 296mm discs with CBS three-piston calipers
Rear Brakes	Single 256 mm disc with 2-piston caliper
Front Tire	120/70ZR-17
Rear Tire	180/55ZR-17
