TuxedoW Home Automation and Security System User Guide
36
Scene Setup
Scenes are used to control connected devices when the system receives a user-defined trigger. The trigger can be the system's clock
and calendar, or the condition of connected devices (locked/unlocked, lights on or off, thermostats reaching a pre-defined
temperature). Scenes can also be triggered manually.
To set up a Scene:
Scene Rules
• Triggers and Conditions include: Time setting, Security mode, Thermostat setting, Door & Garage Door status and Water Valve
status.
• Actions include: Security mode, Lights On/Off, Thermostat setting, Door & Garage Door lock status, Water Valve status and
Recording.
• A Trigger event can initiate as many as 3 Actions.
• A Trigger event and a Condition cannot be the same. For instance, if you set a Security event like Arming as a Trigger, you cannot
select a Security event to serve as a Condition.
• As many as 10 Scenes can be created and saved from the touchscreen itself. However, the system can be operated by up to 20
Scenes coming from Total Connect.
• In commercial systems, the programming option for Global Keypad must be set to “0”. Otherwise, some Scenes will not work
properly.
Note: The Condition is a ‘pre-condition’ set to occur prior to a trigger event. See the example on the next page.
ICON ACTION NOTES
1. On the Home screen, touch Devices
2. Touch SCENE at the bottom of the screen
3. Press Add to set up functions for the new Scene
4. Enter a SCENE NAME and touch the onscreen
keyboard's icon to save it
5. Select a Condition (optional), Trigger and Action
for the Scene. See the example below.
• A Scene must have a trigger and at least one action to work.
The Condition section is optional.
• Don't forget to press SAVE after each setting you enter
Add
Edit
Delete
