AM_8200 Programming Manual PAGE - 61
AM82000_manu-prog-ENG Doc. M-162.1-AM8200-ENG Rev A2 NOTIFIER ITALIA
Zone TEST :
This function allows to start the Walk-Test procedure for a selected zone.
This procedure is composed of 2 folders where the editing function previously explained is applied to enter data.
E
E
n
n
a
a
b
b
l
l
i
i
n
n
g
g
o
o
f
f
a
a
z
z
o
o
n
n
e
e
f
f
o
o
r
r
t
t
h
h
e
e
t
t
e
e
s
s
t
t
f
f
u
u
n
n
c
c
t
t
i
i
o
o
n
n
To change one parameter in this folder select the parameter through the arrow keys (the characters of the
selected field are in Reverse), press the enter key
and use the arrow keys  to change the parameter;
at the end press the enter key to confirm the datum.
O
O
u
u
t
t
p
p
u
u
t
t
s
s
e
e
l
l
e
e
c
c
t
t
i
i
o
o
n
n
In the subsequent programming folder the output to be activated in case of alarm from a device of the test zone
is selected.
To change one or several parameters in this folder select the parameter through the arrow keys (the
characters of the selected field are in Reverse), press the enter key
and use the arrow keys  to change
the parameter; at the end press the enter key to confirm the datum.
LED TEST:
By selecting through the arrow keys  the Led item and by pressing the enter key to confirm, the control
unit performs the lamp-test function (all the control unit leds flash for some seconds)
LCD TEST:
By selecting through the arrow keys  the LCD item and by pressing the enter key to confirm, the control
unit performs the display test.
BUZZER TEST: It will sound intermittently
Enter the zone number for which the test
function must be activated.
(0 = inactive test zone)
CBE Enabling
By selecting CBE Enable.: YES
in case of alarm from the test zone devices
CBEs associated with them are activated
In the “Select” field you can select one of the following
items:
NONE = in case of alarm from the test zone it does not
activate outputs.
SOUNDER = in case of alarm both the Siren output
and all the output modules programmed through Type
– ID “HORN” are activated at each alarm event from
the test zone
The activation duration is 3 sec.
MODULE = in case of alarm from the test zone the
output module programmed in the “ Ind. Mod.” Item
is activated and at each alarm event it will be active for
3 sec.
