AM_8200 Programming Manual PAGE - 69
AM82000_manu-prog-ENG Doc. M-162.1-AM8200-ENG Rev A2 NOTIFIER ITALIA

Examples of programming:
 OPTIONS
The following example points out three ways to perform a simple programming, that is the output module
activation as a response to an alarm on a detector (or any other alarm input device)
OPTION A OPTION B OPTION C
Fire detection device Fire detection device Fire detection device
LOOP 1 - detector 1 LOOP 1 – detector 1 LOOP 1 - detector 1
Output device Output device Output device
LOOP 1 – output module 1 LOOP 1 – output module 1 LOOP 1 – output module 1
Detector equation = (G1) Detector equation = Detector equation = (L1M1)
Module equation = (G1) Module equation = (L1S1) Module equation =
 GENERAL ALARM
The following example shows a method of control unit programming for the general alarm.
The L1M2 output module is associated with the group G1 and will be activated in case of alarm on the L1S1
and L1S2 detectors.
The L1M3 output module is associated with the group G2 and will be activated in case of alarm on the L1S3
detectors or on the L1M1 input module.
The L1M4 output module is used as a general alarm device; it will be activated in case of alarm on any fire
detection device (detector or input module) of the system, because all fire detection devices are associated with
the group G3.
Fire detection
device L1S1
Fire detection
device L1S2”
Fire detection
device L1S3
Fire detection
device L1M1
Software
group
1
Software
group 2
Software
group
3
Output device
L1M2
Output device
L1M3
Output device
L1M4
