EXCEL 500/600 - INSTALLATION INSTRUCTIONS
EN1R-1047GE51 R0913
34
Table 28. DIP switch settings for C-Bus termination
(XCL5010)
DIP switch
setting
communication
speed
controller
location
com-
patibility
up max. 9.6 Kbaud -
XD505A,
XL20XD
middle max. 76.8 Kbaud
middle of
bus
XD508,
XL20XD508
down max. 76.8 Kbaud
beginning or
end of bus
XD508,
XL20XD508
NOTE: Modules listed in Compatibility column are used in
Excel 20/100B/500/600 Controllers.
XC6010 Cable Specifications
For connection of the XC6010 to the XI582 Operator
Interface, two tailor-made cables are available.
— XW564 cable, length 7 ft (2.5 m)
— XW565 cable, length 15 ft (5 m)
to XC6010
(front)
to XI582
XW564 or XW565 (max. 15 m)
SHIELD
1
2
3
4
5
6
R
x
D
G
N
D
+
5
V
E
T
x
D
Y
E
L
L
O
W
B
R
O
W
N
G
R
E
E
N
W
H
I
T
E
1
4
3
2
Fig. 73. Connecting front of XC6010 via XW564 or XW565
to XI582
For connection to the XL-Online PC MMI, a tailor-made cable
is available with plugs on both ends.
— XW567 cable, length 7 ft (2.5 m)
to XC6010
to XL-Online
XW567 (max. 15 m)
SHIELD
1
5
4
3
2
9
8
7
6
1
2
3
4
5
9
7
1
0
8
6
R
x
D
Y
E
L
L
O
W
T
x
D
G
R
E
E
N
G
N
D
G
R
A
Y
Fig. 74. Connecting XC6010 via XW567 to the XL-Online
PC MMI
XC5010C Cable Specifications
The XI582 Operator Interface can be connected to either the
front or the back of the XC5010C.
— XW582 cable, front connection, length 15 ft (5 m)
— XW583 cable, back connection, length 15 ft (5 m)
to XC5010C
XI582
1
5
4
3
2
9
8
7
6
XW582
SHIELD
R
x
D
G
N
D
+
5
V
E
T
x
D
Y
E
L
L
O
W
B
R
O
W
N
G
R
E
E
N
W
H
I
T
E
1
4
3
2
Fig. 75. Connecting front of XC5010C via XW582 to XI582
to XC5010C
XI582
XW583
SHIELD
R
x
D
G
N
D
+
5
V
E
T
x
D
Y
E
L
L
O
W
B
R
O
W
N
G
R
E
E
N
W
H
I
T
E
1
4
3
2
4
5
3
2
Fig. 76. Connecting back of XC5010C via XW583 to XI582
The XL-Online PC MMI can be connected to the front of the
XC5010C CPU module with the following cable:
— XW585 cable, length 15 ft (5 m)
1
5
4
3
2
9
8
7
6
to XC5010C to XL-Online
1
5
4
3
2
9
8
7
6
XW585
SHIELD
+5V
R
x
D
G
N
D
R
T
S
T
x
D
Fig. 77. Connecting front of XC5010C via XW585 to the
XL-Online PC MMI
NOTE: You can also use a standard null modem cable.
An adapter cable XW584 is needed when the same MMI unit
XI582 or XL-Online PC MMI is used on a site where there is a
mix of XC5010C and XC6010 CPU modules. Always use the
new cables XW582 and XW585 with the XC5010C CPU
module and the additional adapter cable XW584 for
connecting to the XC6010 CPU module.
