EXCEL 500/600 - INSTALLATION INSTRUCTIONS
35 EN1R-1047GE51 R0913
XCL5010 Cable Specifications
MMI Cables
Ready-made cables with the shield already connected to the
CPU module plug end are available for the connection of
external MMIs.
Table 29. Cable specifications
MMI type cable length
XI582 (remote MMI) XW582 17 ft (5 m)
XL-Online PC MMI XW585 17ft (5 m)
For connection to the XL-Online PC MMI, a standard null
modem cable may be used.
to XCL5010
XI582
1
5
4
3
2
9
8
7
6
XW582
SHIELD
R
x
D
G
N
D
+
5
V
E
T
x
D
Y
E
L
L
O
W
B
R
O
W
N
G
R
E
E
N
W
H
I
T
E
1
4
3
2
Fig. 78. Connecting XCL5010 via XW582 to XI582
1
5
4
3
2
9
8
7
6
to XCL5010 to XL-Online
1
5
4
3
2
9
8
7
6
XW585
SHIELD
+5V
R
x
D
G
N
D
R
T
S
T
x
D
Fig. 79. Connecting XCL5010 via XW585 to the XL-Online
PC MMI
Modem or ISDN Terminal Adapter Connections
For remote communications, a modem or ISDN terminal
adapter can be connected directly to the serial port of the
XCL5010.
The serial port of the XCL5010 accepts a standard modem
cable with a female 9-pin connector. Use the cable that is
supplied with the modem/ISDN terminal adapter.
The communication speed is 9600 baud by default but can be
set to as high as 38.4 Kbaud.
For more details, see section "Remote Communications" on
page 37.
Changing Between MMI and Modem Connection
The XCL5010 will detect when an MMI or modem/ISDN
terminal adapter is connected and will adjust the
communication speed automatically according to the preset
values. This automatic detection can take up to 5 seconds.
I582
XC5010C
W582
W584
XC6010
PC with
L-Online
W585
W585
W582*
Fig. 80. Excel 500 and Excel 600 used together with XL-Online PC MMI and XI582 Operator Interfaces
NOTE: XI582 units supplied with XW882 cable (for Excel 800 controllers) need an XW884 adapter in order to be connected
with the XC5010 and XCL5010 CPU.
