*OPT (Option Identification)

Query *OPT?

The *OPT query identifies the software installed in the HP 16500C. This

query returns nine parameters. The first parameter indicates whether you

are in the System. The next two parameters indicate any software options

installed, and the next parameter indicates whether intermodule is available

for the System. The last five parameters list the installed software for the

modules in slot A through E for an HP 16500C mainframe. When an

HP 16501A Expansion frame is connected, there will be ten parameters after

the INTERMODULE for modules in slots A through J. A zero in any of the

last eight parameters indicates that the corresponding software is not

currently installed.

Returned Format

{SYSTEM},{<option>|0},{<option>|0},{INTERMODULE|0},{<module>|0}

,{<module>|0},{<module>|0},{<module>|0},{<module>|0}

[,{<module>|0},{<module>|0},{<module>|0},{<module>|0},

{<module>|0}]<NL>

<option> Name of software option

<module> Name of module software

Example OUTPUT XXX;"*OPT?"

Common Commands

*OPT (Option Identification)

9–12

HP 16500C Programmer's Guide
