HP GbE2c - Blc Layer 2/3 Fiber SFP Option Application Guide

OSPF 126
Configuring OSPF for a virtual link on Switch B
1. Configure IP interfaces on each network that will be attached to OSPF areas.
Two IP interfaces are needed on Switch B: one for the transit area network on 10.10.12.0/24 and one for the
stub area network on 10.10.24.0/24.
>> # /cfg/l3/if 1 (Select menu for IP interface 1)
>> IP Interface 1 # addr 10.10.12.2 (Set IP address
on transit area network)
>> IP Interface 1 # mask 255.255.255.0 (Set IP mask
on transit area network)
>> IP Interface 1 # enable (Enable IP interface 1)
>> IP Interface 1 # ../if 2 (Select menu for IP interface 2)
>> IP Interface 2 # addr 10.10.24.1(Set IP address on stub area network)
>> IP Interface 2 # mask 255.255.255.0(Set IP mask on stub area network)
>> IP Interface 2 # enable (Enable IP interface 2)
2. Configure the router ID.
A router ID is required when configuring virtual links. This router ID should be the same one specified as the
target virtual neighbor (nbr) on Switch A.
>> IP Interface 2 # /cfg/l3/rtrid 10.10.14.1(Set static router ID)
3. Enable OSPF.
>> IP# /cfg/l3/ospf/on
4. Define the backbone.
This version of GbE2c software requires that a backbone index be configured on the non-backbone end of the
virtual link as follows:
>> Open Shortest Path First # aindex 0(Select the menu for area index 0)
>> OSPF Area (index) 0 # areaid 0.0.0.0(Set the area ID for OSPF area 0)
>> OSPF Area (index) 0 # enable (Enable the area)
5. Define the transit area.
>> OSPF Area (index) 0 # ../aindex 1 (Select menu for area index 1)
>> OSPF Area (index) 1 # areaid 0.0.0.1(Set the area ID for OSPF area 1)
>> OSPF Area (index) 1 # type transit (Define area as transit type)
>> OSPF Area (index) 1 # enable (Enable the area)
6. Define the stub area.
>> OSPF Area (index) 1 # ../aindex 2 (Select the menu for area index 2)
>> OSPF Area (index) 2 # areaid 0.0.0.2(Set the area ID for OSPF area 2)
>> OSPF Area (index) 2 # type stub (Define area as stub type)
>> OSPF Area (index) 2 # enable (Enable the area)
7. Attach the network interface to the backbone.
>> OSPF Area (index) 2 # ../if 1 (Select OSPF menu for IP interface 1)
>> OSPF Interface 1 # aindex 1 (Attach network to transit area index)
>> OSPF Interface 1 # enable (Enable the transit area interface)
8. Attach the network interface to the transit area.
>> OSPF Interface 1 # ../if 2 (Select OSPF menu for IP interface 2)
>> OSPF Interface 2 # aindex 2 (Attach network to stub area index)
>> OSPF Interface 2 # enable (Enable the stub area interface)
