Hardware Options Installation
Installing a Hard Drive into a Removable Media Bay
To install a hard drive using a drive tray:
1. Complete the “Preparation Procedures” in this chapter.
2. Configure the device:
— For SCSI devices, set the SCSI ID on the drive. You must manually set the
SCSI ID on each device to a unique value in the range of 0 to 6 for each
SCSI bus. Refer to the documentation provided with the device for
instructions on how to set the SCSI ID.
— For IDE (ATAPI or ATA) devices, be sure that the jumper on the drive is set
to Cable Select (CS) so that the drive device ID is determined by the cable.
For more information, refer to “Cabling a Hard Drive” in this chapter.
3. Locate the hard drive screws on the front of the chassis.
HP ProLiant ML330 Generation 3 Server Setup and Installation Guide 4-13
