1–12 Hardware and Software Guide
Component ID
Front Components
Speakers, Jacks Display Release Button
and
Infrared Lens
Component Description
1 Stereo speakers (2) Produce stereo sound.
2 (Consumer) Infrared lens Links the notebook to an optional remote
control.
3
Display release button Opens the notebook.
4 Audio-in
(microphone)
jack
Connects an optional monaural (single
sound channel) microphone.
5 Audio-out (headphone)
jacks (2)
Connect optional headphones or
powered stereo speakers. Also connect
the audio function of an audio/video
device such as a television or
VCR.
