104
Table 117 Logging Setup Page item description
Item Descri
tion
Enable Logging
Specifies if device local logs for Cache and servers are enabled. Console
logs are enabled by default.
Severity level: Specifies the minimum severity level for which a message
will be logged. When a severity level is selected, all severity level choices
above the selection are selected automatically. The possible field values
are:
Emergency: The highest warning level. If the device is down or not
functioning properly, an emergency log message is saved to the
specified logging location.
Alert: The second highest warning level. An alert log is saved, if there
is a serious device malfunction; for example, all device features are
down.
Critical: The third highest warning level. A critical log is saved if a
critical device malfunction occurs; for example, two device ports are
not functioning, while the rest of the device ports remain functional.
Error: A device error has occurred, for example, if a single port is
offline.
Warning: The lowest level of a device warning. The device is
functioning, but an operational problem has occurred.
Notice: Provides device information.
Info: Provides device information.
Debug: Provides debugging messages.
Syslog IP Address Defines the IP Address to upload system Log messages
Syslog Port
Defines the UDP Port through which system Log messages are uploaded.
The field default is 524, and not be modified.
Viewing Logs
The Logging Display Page contains all system logs in a chronological order that are saved in RAM (Cache).
Click Administration Logging Display. The Logging Display Page opens.
Figure 147 Logging Display Page
The Logging Display Page contains the following fields and buttons:
